Flexible Battery Connection Wires
Storage Battery Cable Wiring Harness For Solar Storage System
Suitable For Harsh Outdoor Environments TUV/UL/IEC/CE Certified & 25 Years Lifetime Suitable For PV Plants/Rooftop/Floating Plants Compatible With All Major Solar Connectors Quote Online & Support The Free Samples Category:Battery Storage Cable Tags:Battery Extension Cable, Battery Inverter Cables, Battery Storage Cable
Battery Inverter Cables is a highly flexible cable specially designed for connecting photovoltaic solar systems. It has obtained multiple international certifications such as TUV/UL/IEC/CE/RETIE and complies with UL4703, IEC62930, and EN50618/CPR standards. It is suitable for many different solar power fields such as large-scale solar power stations, rooftop solar power stations, and water-surface floating power stations. This versatile solar cable is designed to meet the different needs of the solar industry. It is suitable for various harsh indoor and outdoor environments such as roofs, deserts, lakes, seasides, and mountains (climates with high temperatures, high humidity, and high salt content). Stable and good connection performance ensures the long-term safe operation of the photovoltaic system, effectively reducing the failure rate and later operation costs of the photovoltaic system. Get your PV installations up and running efficiently and safely. Achieving sustainable and successful PV profitability.
Specification Of Battery Inverter Cables
Product NO. | SC16-10 | Test voltage | 6KV(50Hz,1Min) |
Insulation material | PPO/PC | Contact material | copper, tin-plated |
Rated Voltage | TUV1500V/UL1500V | Contact resistance | less than 0.35 mΩ |
Rated current-2.5mm² | 35A (14AWG) | Degree of protection | IP68 |
Rated current-4mm² | 40A (12AWG) | Ambient temperature | -40℃ up to +120℃ |
Rated Current-6mm² | 45A (10AWG) | Certification | IEC62852 /UL6703 |
